Lenovo Thinkpad E14 Gen 7 21T0005TPH | 14in WUXGA IPS | AMD Ryzen 5 220 | 16GB DDR5 | 512GB SSD | AMD Radeon | Win11 Pro

Technical Specifications:

Processor AMD Ryzen? 5 220 (6C / 12T, 3.2 / 4.9GHz, 6MB L2 / 16MB L3)

AI PC Category Non-AI PC

NPU None

Graphics Integrated AMD Radeon? 740M Graphics

Chipset AMD SoC Platform

Memory 1x 16GB SO-DIMM DDR5-5600

Memory Slots Two DDR5 SO-DIMM slots, dual-channel capable

Max Memory Up to 64GB DDR5-5600

Storage 512GB SSD M.2 2242 PCIe® 4.0x4 NVMe® Opal 2.0

Storage Support Two M.2 slots ? One M.2 2242 PCIe® 4.0 x4 slot ? One M.2 2280 PCIe 4.0 x4 slot

Max Storage Support Up to two drives, 2x M.2 SSD ? M.2 2242 SSD up to 1TB ? M.2 2280 SSD up to 1TB

Card Reader No card reader

Optical High Definition (HD) Audio, Senary SN6147 codec

Audio Chip -

Speakers Stereo speakers, 2W x2, Dolby Atmos®, audio by HARMAN

Microphone 2x, Array

Camera HD 720p with Privacy Shutter

Battery 48Wh

Power Adapter 65W USB-C® (3-pin)

DESIGN

Display 14" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC, 60Hz

Touchscreen None

Screen-to-Body Ratio 90%

Pen Pen Not Supported

Keyboard Backlit, English

Dimensions (WxDxH) 313 x 220.3 x 10.1/15.25 (front/rear), 20.5 (maximum) mm; 12.32 x 8.67 x 0.40/0.60 (front/rear), 0.81 (maximum) inches

Weight Starting at 1.41 kg (3.11 lbs)

Case Color Black

Case Material Aluminium (Top), PC-ABS (Bottom)

-

Surface Treatment -

SOFTWARE

Operating System Windows® 11 Pro, English (US) / English (UK)

Bundled Software None

CONNECTIVITY

Ethernet Wi-Fi® 7, 802.11be 2x2 + BT5.4

WLAN + Bluetooth Non-WWAN

WWAN None

SIM Card 100/1000M (RJ-45)

NFC None

Standard Ports 1x USB-A (USB 5Gbps / USB 3.2 Gen 1)

- 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), Always On

- 1x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with USB PD 3.1 and DisplayPort? 1.4

- 1x USB-C® (USB4® 40Gbps), with USB PD 3.1 and DisplayPort? 1.4a

- 1x HDMI® 2.1, up to 4K/60Hz

- 1x Headphone / microphone combo jack (3.5mm)

- 1x Ethernet (RJ-45)

- -

Optional Ports (configured) -

Docking Various docking solutions supported via USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad E14 Gen 7 (AMD)

SECURITY & PRIVACY

Smart Card Reader Discrete TPM 2.0 Enabled

Security Chip Kensington® Nano Security Slot, 2.5 x 6 mm

Fingerprint Reader None

Physical Locks Touch Style, Match-on-Chip, Integrated in Power Button

Other Security ThinkShield

Camera privacy shutter

MANAGEABILITY

System Management Non-DASH

SERVICE

Warranty 3Y Premier Support Upgrade from 1Y Courier/Carry-in

ACCESSORIES

Bundled Accessories None

CERTIFICATIONS

Green Certifications ENERGY STAR® 9.0

- EPEAT? Gold Registered

- ErP Lot 6/26

- RoHS compliant

- TCO Certified, generation 10

- -

Mil-Spec Test MIL-STD-810H military test passed

- TÜV Rheinland® Low Blue Light (Software Solution)

Other Certifications
