Engineered for Cost-Effective Performance
OCZ Agility 3 SATA III Solid State Drives are designed and built to provide an exceptional
balance of performance and value. The Agility 3 Series implements the cutting-edge SATA 6Gbps
interface to deliver excellent sequential and random data transfer rates, significantly improving
your computing experience over hard drives.
Save More. Do More.
In addition to enhanced performance, an Agility 3 upgrade promotes cooler, quieter, and more
energy efficient conditions compared to traditional mechanical hard drives. With no moving parts,
SSDs provide peace of mind with their superior durability and reliability. Unique and innovative,
Agility 3 SSDs deliver a one-of-a-kind storage solution.
OCZ SSD Features
Less Lag
OCZ SSDs offer industry-leading low latency, enabling faster access to data and a more
responsive computer. Optimize an old notebook or maximize a modern PC.
Proprietary Technology
Its through cutting-edge technology that OCZ has set itself apart from the rest.
Our secret sauce is in our advanced suite of flash management.
Award-Winning Innovation
With innovative storage features, OCZ promises to change your computing expectations and
live up to the hype of using an SSD.
Advanced Endurance
Worried about the lifespan of flash memory? OCZ increases durability and maximizes
the life expectancy of the flash in each SSD.
Beyond the Box
OCZ SSDs deliver lasting performance and reliably long after the initial fresh-out-of-the-box experience.
The SSD Advantage
Faster Performance
SSD technology enables 100x greater throughput, quicker boot ups, faster file transfers,
and overall snappier performance than hard drives.
More Bang for the Buck
When considering performance per dollar, SSDs are more cost-effective
than their mechanical counterparts.
Greater Durability
The non-mechanical design of NAND flash mounted to circuit boards is extremely durable,
unlike HDDs and their rotating disks and seeking spindles.
Energy Efficient
SSDs use significantly less power than hard drives, promoting a longer battery
life in notebooks, less power consumption, and a greener computing environment.
Silent Operation
With no moving parts, SSDs run virtually silent in your notebook or PC to
eliminate distracting noise during gaming or entertainment.
TECH SPECS
| PERFORMANCE | 60-64GB | 90GB | 120GB | 180GB | 240GB | 360GB | 480GB |
|---|
| Sequential Reads 6Gb/s1 | 525MB/s |
| Sequential Writes 6Gb/s1 | 475MB/s | 500MB/s | 500MB/s | 500MB/s | 500MB/s | 495MB/s | 410MB/s |
| Random 4k Read IOPS2 | 10,000 | 20,000 | 20,000 | 35,000 | 35,000 | 35,000 | 35,000 |
| Random 4k Write IOPS2 | 50,000 | 50,000 | 50,000 | 50,000 | 45,000 | 25,000 | 22,000 |
| Max Random 4k Write IOPS3 | 80,000 | 85,000 | 85,000 | 85,000 | 85,000 | 85,000 | 30,000 |
1. Maximum sequential speeds are determined using ATTO
2. Small file I/O performance is measured using IOmeter 2010
3. Maximum I/O performance is measured using IOmeter 2010, 512 bytes Random
Please Note: Current performance specs reflect update to latest firmware.
| PHYSICAL |
|---|
| Usable Capacities (IDEMA) | 480GB |
| NAND Components | 25nm Asynchronous Multi-Level Cell (MLC) |
| Interface | SATA 3 6Gb/s (Backwards compatible with SATA II 3Gb/s) |
| Form Factor | 2.5 Inch |
| NAND Controller | SandForce® 2281 |
| Dimension (L x W x H) | 98 x 69.63 x 9.3mm |
| Weight | 79g |
| RELIABILITY / PROTECTION |
|---|
| MTBF | 2 million hours |
| ECC Recovery | Up to 55 bits correctable per 512-byte sector (BCH) *varies depending on exact configuration |
| Product Health Monitoring | Self-Monitoring, Analysis and Reporting Technology (SMART) support |
| ENVIRONMENTAL |
|---|
| Power Consumption | Idle: 1.5W, Active: 2.7W |
| Operating Temperature | 0°C ~ 70°C |
| Storage Temperature | -45°C ~ 85°C |
| Shock Resistance | 1500G |
| Certifications | RoHS, CE, FCC |
| COMPATABILITY |
|---|
| Serial ATA (SATA) | Fully compliant with Serial ATA International Organization: Serial ATA Revision 3.0. Fully compliant with ATA/ATAPI-8 Standard Native Command Queuing (NCQ) |
| Operating System | Windows XP 32-bit /64-bit; Windows Vista 32-bit / 64-bit; Windows 7 32-bit / 64-bit; Linux; Mac OS X |
| Power Requirement | Standard SATA Power Connector |
| ADDITIONAL FEATURES |
|---|
| Performance Optimization | TRIM (requires OS support) |
| Service & Support | 3-Year Warranty, Toll-Free Tech Support, 24 Hour Forum Support, Firmware Updates |
| ORDERING INFORMATION | PART NUMBER |
|---|
|
|
| 480GB | AGT3-25SAT3-480G |
