TP-Link ER605W Omada AC1200 Gigabit VPN Gateway

Specifications

SECURITY

Access Control
Source/Destination IP Based Access Control

Filtering
Web Group Filtering?
URL Filtering
Web Security?

ARP Inspection
Sending GARP Packets
ARP Scanning?
IP-MAC Binding

Attack Defense
TCP/UDP/ICMP Flood Defense
Block TCP Scan (Stealth FIN/Xmas/Null)
Block Ping from WAN

HARDWARE FEATURES

Interface
1× Gigabit WAN Port
2× Gigabit WAN/LAN Ports
2× Gigabit LAN Ports

Button
Reset Button

Power Supply
12V DC / 1A Power Adapter

Wi-Fi Frequency & Signal Rate
2.4 GHz: 450 Mbps
5 GHz: 867 Mbps

Flash
16 MB NORFLASH

DRAM
128 MB DDR2

LED
Power, SYS, 2.4G, 5G, WAN (1000/100/10M Link/Act), WAN/LAN (1000/100/10M Link/Act)

Dimensions (W × D × H)
8.5 × 4.6 × 1.2 in (215 × 117 × 32 mm)

Antenna
2.4 GHz: 2x 5 dBi non-detachable antennas and 1 built-in antenna
5 GHz: 2x 5 dBi non-detachable antennas

Mounting
Desktop/Wall-mounting

Max. Power Consumption
EU: 10W
US: 12W

PERFORMANCE

Concurrent Session
20,000

New Sessions /Second
1,300

NAT (Static IP)
941.2 Mbps / 937.6Mbps

NAT(DHCP)
933.5 Mbps / 933.6 Mbps

NAT(PPPoE)
919.2 Mbps / 931.9 Mbps

NAT (L2TP)
333.2 Mbps / 387.4 Mbps

NAT (PPTP)
304.2 Mbps / 473.2 Mbps

IPsec VPN Throughput
ESP-SHA1-AES256: 19.7Mbps
ESP-SHA256-AES256: 17.5Mbps
ESP-SHA384-AES256: 13.9Mbps
ESP-SHA512-AES256: 13.9Mbps

OpenVPN
18.0 Mbps

L2TP VPN Throughput
Unencrypted: 307.7 Mbps
Encrypted: 9.8 Mbps

PPTP VPN Throughput
Unencrypted: 319.6 Mbps
Encrypted: 41.9 Mbps

66 Byte Packet Forwarding Rate
1,453,489 pps / 1,453,488 pps

1,518 Byte Packet forwarding rate
81,274 pps / 81,275 pps

WIRELESS FEATURES

Advanced Features
Multiple SSIDs: 8 in total (4 per radio)
Enable/Disable Wireless Radio
Enable/Disable SSID Broadcast
Guest Network
Automatic Channel Selection Algorithm
Transmit Power Control: Adjust transmit Power on dBm
Seamless Roaming
Beamforming
Rate Limit: Based on SSID/Client
Load Balance
Airtime Fairness
Band Steering
RADIUS Accounting
Wireless Encryption: WPA/WPA2 Personal, WPA/WPA2 Enterprise

Guest Network
Support

BASIC FUNCTIONS

WAN Connection Type
Static IP
Dynamic IP
PPPoE (supports MRU Configuration)
PPTP
L2TP

MAC Clone
Modify WAN Address

DHCP
DHCP Server
DHCPv6 PD Server?
DHCP Options Customization
DHCP Address Reservation
Multi-IP Interfaces
Multi-Net DHCP

IPv6
StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode

VLAN
802.1Q VLAN

IPTV
IGMP v2/v3 Proxy, Custom Mode, Bridge Mode

ADVANCED FEATURES

Advanced Routing
Static Routing
Policy Routing

Bandwidth Control
IP-Based Bandwidth Control

Load Balance
Intelligent Load Balance
Application Optimized Routing
Link Backup(Timing, Failover)
Online Detection

NAT
One-to-One NAT
Multi-Net NAT
Virtual Server
Port Triggering?
NAT-DMZ
FTP/H.323/SIP/IPSec/PPTP ALG
UPnP

Session Limit
IP-Based Session Limit

VPN

IPsec VPN
3 IPSec VPN Tunnels
LAN-to-LAN, Client-to-LAN
Main, Aggressive Negotiation Mode
DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
IKE v1/v2
MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm
NAT Traversal (NAT-T)
Dead Peer Detection (DPD)
Perfect Forward Secrecy (PFS)

PPTP VPN
PPTP VPN Server
PPTP VPN Client (3)?
3 Tunnels
PPTP with MPPE Encryption

L2TP VPN
L2TP VPN Server
L2TP VPN Client (3)?
3 Tunnels
L2TP over IPSec

OpenVPN
OpenVPN Server
OpenVPN Client (3)?
18 OpenVPN Tunnels
"Certificate + Account" Mode
Full Mode

AUTHENTICATION

Web Authentication
No Authentication
Simple Password§
Hotspot (Local User / Voucher§ / SMS§ / Radius§)
External Radius Sever
External Portal Sever§
LDAP (not supported in Standalone Mode)

MANAGEMENT FEATURES

Omada App
Yes.

Centralized Management
Omada Cloud-Based Controller
Omada Hardware Controller (OC300)
Omada Hardware Controller (OC200)
Omada Software Controller

Cloud Access
Yes.

Service
Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)

Maintenance
Web Management Interface
Remote Management
Export & Import Configuration
Diagnostics (Ping & Traceroute)?
NTP Synchronize?
Port Mirroring
Syslog Support

Zero-Touch Provisioning
Yes. Require the use of Omada Cloud-Based Controller.

Management Features
Automatic Device Discovery
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
Captive Portal Configuration

OTHERS

Certification
CE, FCC, RoHS

Package Content
ER605W
Power Adapter
Quick Installation Guide

System Requirements
Microsoft Windows 98SE, NT, 2000, XP, Vista? or Windows 7/8/8.1/10/11
MAC OS, NetWare, UNIX or Linux

Environment
Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)
Operating Humidity: 10% to 90% non-condensing
Storage Humidity: 5% to 90% non-condensing
