Hardware Overview

Specifications

Hardware

CPU Model Intel Celeron J4125
CPU Quantity 1
CPU Cores 4
CPU Threads 4
CPU Architecture 64-bit
CPU Frequency 2.0 GHz base / 2.7 GHz turbo
Hardware Encryption Engine Yes

Memory

System Memory 2 GB DDR4 non-ECC
Total Memory Slots 1
Maximum Memory Capacity 6 GB (2 GB + 4 GB)

Notes: Synology may revise pre-installed memory module specifications based on component lifecycle and supply conditions. All revised components undergo validation to ensure compatibility, stability, and performance. For optimal reliability, use Synology memory modules. Non-Synology memory modules may affect warranty and technical support.

Storage

Drive Bays 2
Supported Drive Types 3.5" SATA HDD 2.5" SATA SSD
Hot Swappable Drive Supported

Notes: Synology guarantees full functionality and performance only for compatible drives. Please consult the compatibility list before purchasing drives.

External Ports

RJ-45 1GbE LAN Port 1
RJ-45 2.5GbE LAN Port 1
USB 3.2 Gen 1 Port 2
USB Copy Supported

Notes: MTU value of the 1GbE LAN port has a limit of 1500.

Appearance

Dimensions 165 mm x 108 mm x 232.2 mm
Weight 1.3 kg

System Features

System Fan 92 mm x 92 mm x 1 pc
Fan Speed Mode Full-Speed Mode Cool Mode Quiet Mode
Brightness Adjustable Front LED Indicators Yes
Power Recovery Yes
Noise Level 19.6 dB(A)
Scheduled Power On/Off Yes
Wake on LAN / WAN Yes

Power

Power Supply Unit 60 watts
AC Input Voltage 100V to 240V AC
Power Frequency 50/60 Hz Single Phase
Power Consumption 16.98 watts (Access) 6.08 watts (HDD Hibernation)
British Thermal Unit 57.90 BTU/hr (Access) 20.73 BTU/hr (HDD Hibernation)

Temperature and Humidity

Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Operating Humidity 8% to 80% RH
Storage Humidity 5% to 95% RH

Certification

FCC CE BSMI VCCI RCM UKCA EAC CCC KC BIS

Environment

RoHS Compliant

Packaging Content

Main Unit x1
Accessory Pack x1
AC Power Adapter x1
AC Power Cord x1
RJ-45 LAN Cable x2
