| Printer | |||
| Maximum Printing Resolution | 4800 (horizontal)*1 x 600 (vertical) dpi | ||
| Print Head / Ink | Type: | FINE Cartridge | |
| Number of Nozzles: | Total 1,280 nozzles | ||
| Ink Droplet Size: | 2pl | ||
| Ink Tank: | PG745, CL-746 (Optional: PG-745XL, CL-746XL) | ||
| Print Speed*2 Based on ISO / IEC 24734. Click here for summary report Click here for Document Print and Copy Speed Measurement Conditions | Document: Col | ESAT / Simplex | approx. 4.0ipm |
| Document: B / W | ESAT / Simplex | approx. 8.0ipm | |
| Printable Width | Up to 203.2mm (8inch) | ||
| Borderless Printing | Top margin: 3mm, Bottom margin: 16.7mm, Left / Right margin: each 3.4mm (LTR / LGL: Left: 6.4mm, Right: 6.3mm) | ||
| Recommended Printing Area | Top margin: 31.6mm / Bottom margin: 29.2mm | ||
| Paper Size | A4, A5, B5, LTR, LGL, 4 x 6", 5 x 7", Envelopes (DL, COM10), Custom size (width 101.6mm - 215.9mm, length 152.4mm - 676mm) | ||
| Paper Handling (Rear Tray) (Maximum Number) | Plain Paper | A4, A5, B5, LTR=60, LGL=10 | |
| Photo Paper Plus Glossy II (PP-201) | 4 x 6"=20 | ||
| Glossy Photo Paper "Everyday Use" (GP-601) | 4 x 6"=20 | ||
| Envelope | European DL / US Com. #10=5 | ||
| Paper Weight | Rear Tray | Plain Paper: 64-105 g/m2 , Canon specialty paper: max paper weight : approx. 275 g/m2(Photo Paper Plus Glossy II (PP-201)) | |
| Ink End Sensor | Dot count | ||
| Print Head Alignment | Manual | ||
| System Requirements | |||
| Windows: | (Please visit www.canon-asia.com to check OS compatibility and to download the latest driver updates.) | Windows 8 / Windows 7 / Windows XP / Windows Vista | |
| Macintosh: | Mac OS X v10.6.8 and later | ||
| General Specifications | |||
| Interface | USB 2.0 Hi-Speed | ||
| Operating Environment | Temperature: 15 -30°C; Humidity: 10 - 80% RH (no dew condensation) | ||
| Storage Environment | Temperature: 0 - 40°C; Humidity: 5 - 95% RH (no dew condensation) | ||
| Power | AC 100-240V 50 / 60Hz | ||
| Power Consumption | Standby (USB connection to PC) | Approx. 0.8W | |
| OFF: | Approx. 0.5W | ||
| Printing *4 | Approx. 8.0W | ||
| Environment | Regulation: | RoHS (EU, China), WEEE (EU) | |
| Eco-Label: | Energy Star, EPEAT | ||
| Dimension (W x D x H) | approx. 426 x 235 x 134mm | ||
| Weight | approx. 2.3kg | ||
