Specifications |
 |
Type of Camera
|
Compact digital still camera with built-in flash, 6x Optical / 4x Digital / 24x Combined Zoom with Optical Image Stabilizer System
|
Type
|
12.1 Megapixel, 1/1.7 inch type Charge Coupled Device (CCD)
|
Total Pixels
|
Approx. 12.4 Megapixels
|
Effective Pixels
|
Approx. 12.1 Megapixels
|
Focal Length
|
7.4-44.4mm f/2.8-4.8 (35mm film equivalent: 35-210mm)
|
Digital Zoom
|
4x
|
Focusing Range
|
Normal: 1.6 ft./50cm-infinity
Macro: 0.39 in.-1.6 ft./1-50cm (WIDE)
|
Autofocus System
|
TTL Autofocus
|
Viewfinder
|
Real image optical zoom viewfinder
|
LCD Monitor
|
3.0 inch low-temperature polycrystalline silicon TFT color LCD with wide viewing angle
|
LCD Pixels
|
Approx. 230,000 pixels
|
LCD Coverage
|
100%
|
Maximum Aperture
|
f/2.8 (W) - f/4.8 (T)
|
Shutter Speed
|
15-1/2500 sec. (settable in Tv and M)
|
ISO Sensitivity
|
Auto, High ISO Auto, ISO 80/100/200/400/800/1600 equivalent (Standard Output Sensitivity. Recommended Exposure Index)
|
Light Metering Method
|
Evaluative*, Center-weighted average, Spot**
* Control to incorporate facial brightness in Face Detection AF
** Metering frame is fixed to the center or linked to the AF frame
|
Exposure Control Method
|
Program AE, Shutter Speed-Priority AE, Aperture-Priority AE, Manual; AE Lock, Safety Shift, Auto ISO Shift
|
Exposure Compensation
|
+/-2 stops in 1/3-stop increments
|
White Balance Control
|
Auto, Preset (Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H, Flash, Underwater), Custom1, Custom2
|
Built-in Flash
|
Auto, Auto w/ Red-eye Reduction, Flash On, Flash On w/ Red-eye Reduction, Flash Off; FE lock, Safety FE, Slow Synchro, Second-curtain synchro
|
Flash Range
|
1.0-13 ft./30cm-4.0m (W), 1.6-8.2 ft./50cm-2.5m (T) (when sensitivity is set to ISO Auto)
|
Recycling Time
|
12 sec. or less (battery voltage=7.4V)
|
Flash Exposure Compensation
|
+/-2 stops in 1/3-stop increments
|
Shooting Modes
|
Auto, P, Av, Tv, M, C1, C2, Special Scene (Portrait, Landscape, Night Scene, Sports, Foliage, Snow, Beach, Fireworks, Aquarium, Underwater, Indoor, ISO 3200, Kids & Pets, Night Snapshot, Color Accent, Color Swap), Stitch Assist, Movie
|
Photo Effects
|
My Colors
Vivid, Vivid Blue, Vivid Green, Vivid Red, Neutral, Sepia, Black & White, Positive Film, Lighter Skin Tone, Darker Skin Tone, Custom
|
Self-Timer
|
Activates shutter after an approx. 2-sec./10-sec. delay, Custom
|
Wireless Control
|
Not available
|
Continuous Shooting
|
Normal: approx. 1.5 fps; AF: approx. 0.7 fps; LV: approx. 0.8 fps (Large/Fine)
|
|
Storage Media
|
SD/SDHC Memory Card, MultiMediaCard, MMC Plus Card, HC MMC Plus Card
|
File Format
|
Design rule for camera file system, DPOF Version 1.1
|
Image Compression
|
Normal, Fine, SuperFine, RAW
|
JPEG Compression Mode
|
Still Image: Exif 2.2 (JPEG)
Movie: AVI (Image: Motion JPEG; Audio: WAVE (Monaural))
|
Number of Recording Pixels
|
Still Image: 4,000 x 3,000 (Large), 3,264 x 2,448 (Medium 1), 2,592 x 1,944 (Medium 2), 1,600 x 1,200 (Medium 3), 640 x 480 (Small), 4,000 x 2,248 (Widescreen)
Movie: 1024 x 768 (15 fps), 640 x 480 (30 fps/30 fps LP), 640 x 480 (2 hours at 0.5 fps/1 fps), 320 x 240 (30 fps) available up to 4GB or 60 minutes, 160 x 120 (3 minutes at 15 fps)
|
|
| |
Large (L) |
Medium 1 (M1) |
Medium 2 (M2) |
| SF |
F |
N |
SF |
F |
N |
SF |
F |
N |
| File Size (KB) |
5,208 |
3,084 |
1,474 |
3,436 |
2,060 |
980 |
2,503 |
1,395 |
695 |
| 32MB |
5 |
9 |
20 |
8 |
14 |
30 |
11 |
21 |
42 |
| SDC-128M |
23 |
39 |
82 |
35 |
59 |
123 |
49 |
87 |
173 |
| SDC-512MSH |
91 |
155 |
321 |
139 |
231 |
479 |
190 |
339 |
671 |
| |
Medium 3 (M3) |
Small (S) |
Widescreen (W) |
RAW |
| SF |
F |
N |
SF |
F |
N |
SF |
F |
N |
RAW |
+JPEG |
| File Size (KB) |
1,002 |
558 |
278 |
249 |
150 |
84 |
3,903 |
2,311 |
1,105 |
17,076 |
20,160 |
| 32MB |
30 |
53 |
102 |
114 |
177 |
278 |
7 |
12 |
27 |
1 |
1 |
| SDC-128M |
121 |
217 |
411 |
460 |
711 |
1,118 |
31 |
53 |
109 |
6 |
5 |
| SDC-512MSH |
471 |
839 |
1,590 |
1,777 |
2,747 |
4,317 |
122 |
206 |
425 |
27 |
23 | |
|
| |
Standard, Color Accent, Color Swap |
High Resolution |
Compact |
Time Lapse |
| 640 x 480 |
320 x 240 |
1,024 x 768 |
160 x 120 |
640 x 480 |
| 30 fps |
30 fps LP |
30 fps |
15 fps |
15 fps |
1 sec. interval |
2 sec. interval |
| Movie size (KB/sec.) |
1,963 |
1,003 |
703 |
1,963 |
131 |
64 |
32 |
| 32MB |
14" |
28" |
40" |
14" |
3' 15" |
7' 45" |
15' 30" |
| SDC-128M |
1' 01" |
1' 55" |
2' 42" |
1' 01" |
13' 02" |
31' 45" |
63' 30" |
| SDC-512MSH |
3' 57" |
7' 30" |
10' 29" |
3' 57" |
50' 21" |
123' 30" |
247' 00" | Note: N=Normal F=Fine SF=SuperFine
Storage Capacity varies depending on camera settings. This data is estimated from Canon's standard shooting conditions. Figures for Movie Mode represent total capacity of the particular media. |
Playback Modes File
|
Still Image: Single, Magnification (approx. 2x-10x), Jump, Auto Rotate, Rotate, Resume, My Colors, My Category, Histogram, Index (9 thumbnails), Sound Memos, Slide Show, Red-eye Correction, RAW playback, Resize, Image Inspection Tool
Movie: Normal Playback, Special Playback, Editing
|
Erase Modes
|
Still Image: single image, select by date, select by category, select by folder, all images
Movie: part of movie, all of movie
|
Computer Interface
|
USB 2.0 Hi-Speed (mini-B jack)
|
Video Out
|
NTSC/PAL
|
Audio Out
|
Monaural
|
Other
|
SD Memory card slot; direct connection to Canon CP and SELPHY Compact Photo Printers, PIXMA Photo Printers and PictBridge-compatible printers via camera's USB 2.0 Hi-Speed cable
|
Power Source
|
1. Rechargeable Lithium Battery NB-2LH
2. AC Adapter Kit ACK-DC20 (optional)
|
Shooting Capacity
|
Still Image: approx. 240 shots (NB-2LH/LCD on)*, approx. 600 shots (NB-2LH/LCD off)
* LCD screen on. The above figures comply with CIPA testing standards and apply when fully-charged batteries are used.
|
Playback Time
|
Approx. 300 min. (NB-2LH)
|
Operating Temperature
|
32-104°F/0-40°C
|
Operating Humidity
|
10-90%
|
Dimensions (W x H x D)
|
4.19 x 2.83 x 1.67 in. / 106.4 x 71.9 x 42.5mm
|
Weight
|
Approx. 11.29 oz. / 320g (camera body only)
|
 | |
 |
| |
